The D-Link DGS-1510 Series is the latest generation of Smart Managed switches with 10G SFP+ fibre ports for physical stacking or uplinks. The combination of high bandwidth connections, an Industry Standard CLI, and PoE options make the DGS-1510 Series ideal for Small-Medium Enterprise environments.
Fully‑Featured with Layer 3 Traffic Management
The DGS-1510 family has advanced network management options, accessible via Industry Standard CLI, Serial Port Console or the Web-based UI, that equip your business with network capabilities such as VLANs, multiple spanning tree protocol (MSTP), link aggregation (LACP), static routing, multiple firmware images,and multiple configuration files.
10G SFP+ Stacking
Create a physical stack of up to 6 units in a fault‑tolerant ring or linear topology using Direct Attach Cables or any compatible SFP+ transceivers for a total of 288 Gigabit ports. The remaining uplink ports can be used for other functions, offering 10G connectivity to core networks and servers.1
With powerful security features like IGMP snooping, access control lists, port security, and the unique D-Link Safeguard Engine that protects your network against malicious denial-of-service attacks from broadcast, multicast and unicast flooding, the DGS-1510 family is a versatile solution for enterprise network environments.
Powerful Network Design and Management Software
The DGS-1510 Series supports D-View 8, an intelligent management platform that allows for centralized management of the core network. This extensive toolset enables administrators to easily set up and remotely manage their networks, greatly reducing switch deployment time.
Max PoE with budgets up to 740W2
Choose between 193W and 370W power budget options. Or utilise a total of 740W when adding a redundant power supply to the DGS-1510-52XMP.
Smart Energy‑Saving Design
D-Link Green technology enables the DGS-1510 series to save power without sacrificing performance. The entire series of switches feature a smart fan that adjusts fan-speed and only powers on above a certain temperature. With advanced silicon technology, the DGS-1510 series saves up to 73% of energy compared to normal switches.
When stacking in a linear typology, the remaining unused SFP+ ports in the stacking port pair of the top and bottom switches will also be considered occupied by the switch and cannot be used for any other purpose.
Power Budget of 740W is achieved when using an optional DPS-700 RPS redundant power supply on the DGS-1510-52XMP. Up to 30W per port.
Tech Specifications
Hardware
FAN
2 DC Fans
Wireless
Interfaces
4 x 10G SFP+ ports
24 x 10/100/1000BASE-T PoE ports
General
Switch Capacity
128 Gbps
PoE Power Budget
370 W
Max. Packet Forwarding Rate
95.24 Mpps
Maximum Heat Dissipation
1,487.78 BTU/hr
Max Power Consumption
436.3 W (PoE on)
38.4 W (PoE off)
MTBF
274,796 hours
Power Input
AC:100 ~ 240 V
CPU Speed
400MHz
Flash Memory Size
32 MB
DRAM Size
256MB
Packet Buffer Size
1.5MB
Physical
Humidity
Operating: 0% - 95% RH
Storage: 0% - 95% RH
Temperature
Operating: -5 to 50° C (23 to 122° F)
Storage -20 - 70°C
Dimensions
440 x 308.5 x 44mm
Weight
4.25 kg
