Conserve Energy

The 8-Port Gigabit Easy Desktop Switch helps you conserve energy automatically through several methods. It automatically powers down ports that have no link, allowing the switch to save a substantial amount of power by cutting power usage for unused ports or ports connected to computers that have been shut down.

Environmentally Friendly

The 8-Port Gigabit Easy Desktop Switch was designed with the environment in mind, and is compliant with Energy Star Level V, as well as with the stringent CEC and MEPS regulations that require the use of energy efficient power adapters. The switch is also built to follow RoHS standards to minimize use of hazardous materials, and uses recyclable packaging that helps reduce waste, complying with the WEEE directive.

Tech Specifications

Hardware
Device Interfaces

• 8 x 10/100/1000BASE-T ports

Media Interface Exchange

• Auto MDI/MDIX adjustment for all ports

Power

• DC 5V / 1A

Wireless
Wireless

Standards

• IEEE 802.3 10BASE-T
• IEEE 802.3u 100BASE-T
• IEEE 802.3ab 1000BASE-T
• IEEE 802.3az Energy-Efficient Ethernet (EEE)
• IEEE 802.3x Flow Control
• IEEE 802.1p QoS

General
Transmission Method

• Store-and-forward

Switching Capacity

• 16 Gbps

Max. Packet Forwarding Rate

• 11.9 Mpps

MAC Address Table

• 8K entries

MAC Address Learning

• Automatic update

Packet Buffer

• 4 MB

Physical
LED Indicators

• Per port: Link/Activity

• Per device: Power

Dimensions

• 127 x 67 x 20 mm mm

Weight

• 0.1 kg
