Plug and play
Extending your network never been so easy
With DHP-P601AV starter kit, you can extend your network connection through
electric cable without any configuration.
Up to 1000Mps
Based on latest Homeplug AV2 standard and gigabit port, you can enjoy fast
network speed within your home. Ideal for intensive application such
Streaming HD or 4K content and online gaming.
Extra Socket
With passthrough, you can enjoy powerline technology and yet without sacrifice
a power outlet. With built-in noise filter, it will prevent to plug in equipment from
affecting its performance.
Going Green
Love our Earth. DHP-601AV with its power saving function can save up to 85% energy.
Specifications
| Powerline Interface | • Power plug (country-dependent) | |
| Ethernet Interface | • RJ-45 Gigabit Ethernet LAN port | |
| Standards | • IEEE 802.3 • IEEE 1901 • IEEE 802.3u • HomePlug AV2 |
|
| Security | • 128-bit AES data encryption | |
| LEDs | • Power • PowerLine • Ethernet |
|
| Powerline Modulation Scheme | • OFDM Symbol Modulation | |
| Powerline Frequency Band | • 2 MHz to 86 MHz | |
| Data Rate | • Ethernet: 10/100/1000 Mbps (auto negotiation) • PowerLine: Up to 1000 Mbps (PHY rate) |
|
| Dimensions | • 113.49 x 58.48 x 37.8 mm ( 4.47 x 2.30 x 1.49 inches) each adapter | |
| Weight | • 195 grams (0.42 lbs) each adapter | |
| Power | • Input: 100 to 240 V AC, 50/60 Hz | |
| Power Consumption | • 3.7 W maximum (each adapter) | |
| Temperature | • Operating: 0 to 40 °C (32 to 104 °F) • Storage: -20 to 65 °C (-4 to 149 °F) |
|
| Humidity | • Operating: 10% to 90% non-condensing • Storage: 5% to 95% non-condensing |
|
| Certifications | • CE • CE/LVD |
